Package Treatment Plants

Delta Package Treatment Plants are designed to convert flows of 3,000 to 100,000 gallons per day into clear and odor-free effluent.

Delta Package Treatment Plants are custom designed to the particular needs of each location. Suitable for permanent or temporary use in areas outside municipal wastewater systems, each Delta Package Treatment Plant is custom-built at the factory and shipped to the project site as a self-contained unit that requires minimal assembly.

Secondary and tertiary treatment systems include aeration, settling, filters, clear well chambers, disinfection methods and other ancillary equipment such as blowers, pumps, electrical controls, aeration equipment, filter media and liquid level sensors. Other items, such as gratings, handrails, stairways and flow measuring equipment can be provided. A Delta Treatment Systems representative can assist you in specifying the system that will meet your requirements.


How Delta Package Treatment Plants Work:

When waste enters a stream, it becomes food for bacteria present in the water. As long as there is sufficient oxygen in the stream, the bacteria consumes all organic material over time. Delta Package Treatment Plants use the same process to break down domestic wastewater, only it does it faster and more efficiently.

Self-contained Delta Package Treatment Plants take in wastewater and process it through an extended aeration and oxidation process that purifies the sewage by the destruction of organic compounds using naturally occurring bacteria. The continued mixing with air feeds biological organisms, which consume the volatile materials and convert them into water, carbon dioxide, and ash. The result is a clear and odor-free effluent.

A typical Delta Package Treatment Plant includes the following elements:

Packaged Wastewater Treatment Plant

A. Air Blower Unit
B. Electrical Control Console
C. Aeration Chamber
D. Service Walkway/Grating
E. Secondary Clarifier with Chlorination


The Perfect Wastewater Treatment Solution for Remote Locations

Delta Package Treatment Plants offer options beyond individual septic systems or costly sewer connection to builders and site developers.

Because Delta Package Treatment Plants can be pad-mounted, terrain or soil conditions are not a factor when selecting an installation site. Delta Package Treatment Plants are self-contained units that effectively process the wastewater turning out high-grade, clear effluent. Delta’s Package Treatment Plants can also be installed at grade depending on site conditions.

Typical application settings for Delta Package Treatment Plants:

  • Remote housing developments and neighborhoods
  • Motels and hotels
  • Schools
  • Hospitals
  • Resort areas
  • Apartment or Condominium Complexes
  • Military facilities
  • Highway rest areas
  • Prisons
  • Industrial facilities
  • Power stations
  • Mobile home parks
  • Vineyards

Package Treatment Plants Case Studies
